RF-Solution
1. Application
Remote lighting control of street lights, parking lot, solar lights, factory, park and etc.
2. Main Feature
- RF(Radio frequency which including Zigbee) communication, point-to-point transmission distance is up to 150m, the total distance after automatic relay by the lamp controllers is up to 4km.
- Up to 200 lamp controllers can be managed by a concentrator or a gateway.
- The lamp controller can control lighting fixtures such as sodium lamp, LED lamp and ceramic metal halide lamp with power up to 400W.
- It supports three dimming modes: PWM, 0-10V and DALI.
- The lamp controller is automatically networked with data transmission rate is 256Kbps, private network without additional communication fee.
- Remote real time control and scheduled lighting by group or individual lamp, remote control on the power circuit(when a concentrator installed in the cabinet, not available for gateway).
- Alarm on the power supply of the cabinet and lamp parameters.
- Pole tilt, GPS, RTC options
Remote lighting control of street lights, parking lot, solar lights, factory, park and etc.
2. Main Feature
- RF(Radio frequency which including Zigbee) communication, point-to-point transmission distance is up to 150m, the total distance after automatic relay by the lamp controllers is up to 4km.
- Up to 200 lamp controllers can be managed by a concentrator or a gateway.
- The lamp controller can control lighting fixtures such as sodium lamp, LED lamp and ceramic metal halide lamp with power up to 400W.
- It supports three dimming modes: PWM, 0-10V and DALI.
- The lamp controller is automatically networked with data transmission rate is 256Kbps, private network without additional communication fee.
- Remote real time control and scheduled lighting by group or individual lamp, remote control on the power circuit(when a concentrator installed in the cabinet, not available for gateway).
- Alarm on the power supply of the cabinet and lamp parameters.
- Pole tilt, GPS, RTC options
